| 工作电压 | 3.4 V ~ 4.3 V, typical: 3.8 V |
| 尺寸 | 40.0 mm x 30.0 mm x 2.85 mm |
| 封装 | LGA |
| 工作温度 | -30℃ ~ +70℃ |
| 接口 | PCIe Gen 2 USB 2.0/3.1 I2S UART USIM (1.8 V/3.0 V) |
| 频段 | 5G NR: n1/n28/n41/n77/n78/n79; LTE: B1/B3/B5/B8/B34/B38/B39/B40/B41; UMTS: B1/B5/B8 |
| 协议 | PPP/RNDIS/TCP/UDP/FTP/HTTP/HTTPS/NTP/ IPv4/IPv6 |
| 认证 | CCC/SRRC/CTA |
| 区域 | China/SEA/Japan |
